Housing:
Extruded Aluminum made of 3.875" wide profile. LED surface-mounted luminaire. Direct only light distribution. 13 different diameters from 2' to 26'. Fully enclosed and damp rated.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Surface white, silver, graphite, black, champagne, or copper coated. For further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low or Medium Power. Custom lumen output upon request. Lifetime L85/50000h.
Certification & Warranty:
cETLus. 5 Years Warranty.
![](/site/assets/files/5554/ringo-star-system-100mm-surface-a1-0001-.0x556.png)
![](/site/assets/files/5554/ringo-star-system-100mm-surface-a1-0002.0x556.png)
![](/site/assets/files/5554/ringo-star-system-100mm-surface-a1-0003.0x556.png)
![](/site/assets/files/5554/ringo-star-system-100mm-surface-a1-0004.0x556.png)
![](/site/assets/files/5554/ringo-star-system-100mm-surface-a1-0005.0x556.png)
Product adjustments
![](/site/assets/files/6072/ringo-star-g1p1-system-100mm-suspended-white.92x92.jpg)
Snow White
![](/site/assets/files/6073/ringo-star-g1p1-system-100mm-suspended-silver.92x92.jpg)
Radiant Silver
![](/site/assets/files/6074/ringo-star-g1p1-system-100mm-suspended-graphite.92x92.jpg)
Urban Graphite
![](/site/assets/files/6075/ringo-star-g1p1-system-100mm-suspended-black.92x92.jpg)
Jet Black
![](/site/assets/files/6080/ringo-star-g1p1-system-100mm-suspended-champagne.92x92.jpg)
Anodic Champagne
![](/site/assets/files/6081/ringo-star-g1p1-system-100mm-suspended-copper.92x92.jpg)
Satin Copper
Configuration and data download
Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Luminous Flux | Power consumption |
---|---|---|---|---|---|---|---|---|---|
1RA1ABD-835E-D8000 | Ringo Star-A1 | D=315'' | Microprismatic screen | Jet Black | 3500K | Dimmable (0-10V) | 61100lm | 528W | |
1RA1AWD-830E-D1200 | Ringo Star-A1 | D=47,2'' | Microprismatic screen | Snow White | 3000K | Dimmable (0-10V) | 8228lm | 77W | |
1RA1ASD-830E-D1200 | Ringo Star-A1 | D=47,2'' | Microprismatic screen | Radiant Silver | 3000K | Dimmable (0-10V) | 8228lm | 77W | |
1RA1OSD-827M-D1200 | Ringo Star-A1 | D=47,2'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 10425lm | 91W | |
1RA1OSD-827M-D1500 | Ringo Star-A1 | D=59,1'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 13417lm | 121W | |
1RA1OSD-827M-D2000 | Ringo Star-A1 | D=78,7'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 18794lm | 169W | |
1RA1OSD-827M-D2500 | Ringo Star-A1 | D=98,4'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 23375lm | 204W | |
1RA1OSD-827M-D3000 | Ringo Star-A1 | D=118,1'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 28798lm | 250W | |
1RA1OSD-827M-D3500 | Ringo Star-A1 | D=137,8'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 32379lm | 281W | |
1RA1OSD-827M-D4000 | Ringo Star-A1 | D=157,5'' | Opal diffuser | Radiant Silver | 2700K | Dimmable (0-10V) | 37774lm | 331W |
