Housing:
Extruded Aluminum. LED surface-mounted luminaire for walls or ceilings. Direct light distribution and indirect lighting corona or direct only light distribution. in 5 different diameters from 15.75" to 47.25". Fully enclosed and damp rated.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Opal diffuser made of acrylic glass.
Surface Finish:
Surface white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low or Medium Power. Lifetime L85/50000h.
Certification & Warranty:
cETLus. 5 Years Warranty.
![](/site/assets/files/5573/basic-max-surface-x1-y1-0001-.0x556.png)
![](/site/assets/files/5573/basic-max-surface-x1-y1-0002.0x556.png)
![](/site/assets/files/5573/basic-max-surface-x1-y1-0003.0x556.png)
![](/site/assets/files/5573/basic-max-surface-x1-y1-0004.0x556.png)
![](/site/assets/files/5573/basic-max-surface-x1-y1-0005.0x556.png)
Product adjustments
![](/site/assets/files/5381/basic-superflat-surface-snow-white-002-kopie.92x92.jpg)
Snow White
![](/site/assets/files/5382/basic-superflat-surface-radiant-silver-002-kopie--.92x92.jpg)
Radiant Silver
![](/site/assets/files/5383/basic-superflat-surface-urban-graphite-002-kopie.92x92.jpg)
Urban Graphite
![](/site/assets/files/5384/basic-superflat-surface-jet-black-002-kopie.92x92.jpg)
Jet Black
![](/site/assets/files/5385/basic-superflat-surface-satin-titanium-002-kopie.92x92.jpg)
Anodic Champagne
![](/site/assets/files/5386/basic-superflat-surface-satin-copper-002-kopie.92x92.jpg)
Satin Copper
Configuration and data download
Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Luminous Flux | Power consumption |
---|---|---|---|---|---|---|---|---|---|
1BY1OBD-840M-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Jet Black | 4000K | Dimmable (0-10V) | 1780lm | 13W | |
1BY1OBE-830M-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Jet Black | 3000K | Switchable | 1664lm | 13W | |
1BY1OWE-840M-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Snow White | 4000K | Switchable | 1780lm | 13W | |
1BY1OSE-840M-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Radiant Silver | 4000K | Switchable | 1780lm | 13W | |
1BY1OBE-830E-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Jet Black | 3000K | Switchable | 851lm | 7W | |
1BY1OBD-830M-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Jet Black | 3000K | Dimmable (0-10V) | 1664lm | 13W | |
1BY1OSE-830E-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Radiant Silver | 3000K | Switchable | 851lm | 7W | |
1BY1OSD-835E-D300 | Basic-Y1 | D=11,8'' | Opal diffuser | Radiant Silver | 3500K | Dimmable (0-10V) | 910lm | 7W | |
1BY1ASE-835E-D300 | Basic-Y1 | D=11,8'' | Microprismatic screen | Radiant Silver | 3500K | Switchable | 800lm | 7W | |
1BY1ASE-830E-D600 | Basic-Y1 | D=23,6'' | Microprismatic screen | Radiant Silver | 3000K | Switchable | 3609lm | 25W |
