Housing:
Extruded Aluminum. LED surface-mounted luminaire for walls or ceilings. Direct only light distribution. Fully enclosed.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Surface white, silver, graphite, black, champagne, or copper coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Medium or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Certification & Warranty:
cETLus. 5 Years Warranty.
Product adjustments
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|
| 1BA5OSD-830M-D300 | Basic-A5 | D=11,8'' | Opal diffuser | Radiant Silver | 3000K | Dimmable (0-10V) | 655lm | 7W | |
| 1BA5OBD-840H-D300 | Basic-A5 | D=11,8'' | Opal diffuser | Jet Black | 4000K | Dimmable (0-10V) | 1200lm | 11W | |
| 1BA5AWE-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Snow White | 3500K | Switchable | 690lm | 7W | |
| 1BA5ASE-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Radiant Silver | 3500K | Switchable | 690lm | 7W | |
| 1BA5ABE-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Jet Black | 3500K | Switchable | 690lm | 7W | |
| 1BA5AWD-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Snow White | 3500K | Dimmable (0-10V) | 690lm | 7W | |
| 1BA5ASD-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Radiant Silver | 3500K | Dimmable (0-10V) | 690lm | 7W | |
| 1BA5ABD-835M-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Jet Black | 3500K | Dimmable (0-10V) | 690lm | 7W | |
| 1BA5AWE-835H-D300 | Basic-A5 | D=11,8'' | Microprismatic screen | Snow White | 3500K | Switchable | 1190lm | 11W | |
| 1BA5OWE-830M-D300 | Basic-A5 | D=11,8'' | Opal diffuser | Snow White | 3000K | Switchable | 655lm | 7W |
