Housing:
Extruded Aluminum. Recessed mounted LED light system with frame for installation in ceilings with cut-out openings. Direct only light distribution. Luminaire body with smooth bends made of profile with 2.375" optics width, crafted in one piece with no visible seams. Fully enclosed and damp rated.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting.
Surface Finish:
Standard color finishes white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3 -step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low, Medium, or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Certification & Warranty:
cETLus. 5 Years Warranty.
Product adjustments
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Optical system | Surface finish | Color temperature | Control | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|
| 1QF3ASE-835H-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Radiant Silver | 3500K | Switchable | 700lm/feet | 9W/feet | |
| 1QF3ASE-835M-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Radiant Silver | 3500K | Switchable | 540lm/feet | 7W/feet | |
| 1QF3ASE-835E-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Radiant Silver | 3500K | Switchable | 370lm/feet | 5W/feet | |
| 1QF3ABE-835H-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Jet Black | 3500K | Switchable | 700lm/feet | 9W/feet | |
| 1QF3ABD-835M-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Jet Black | 3500K | Dimmable (0-10V) | 540lm/feet | 7W/feet | |
| 1QF3ABD-835H-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Jet Black | 3500K | Dimmable (0-10V) | 700lm/feet | 9W/feet | |
| 1QF3ABE-835M-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Jet Black | 3500K | Switchable | 540lm/feet | 7W/feet | |
| 1QF3ABE-835E-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Jet Black | 3500K | Switchable | 370lm/feet | 5W/feet | |
| 1QF3ASD-835H-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Radiant Silver | 3500K | Dimmable (0-10V) | 700lm/feet | 9W/feet | |
| 1QF3ASD-835M-STRUCTURE_Lxxxx | Liquid Line-F3 | Microprismatic screen | Radiant Silver | 3500K | Dimmable (0-10V) | 540lm/feet | 7W/feet |
