Housing:
Extruded Aluminum. LED pendant luminaire made with 3.875" profile width. Direct-Indirect or Direct only light distribution with separate compartments. 5 different diameters from 2' to 7'. Fully enclosed and damp rated.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Surface white, silver, graphite, black, champagne, or copper coated. For further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice. Internal sound absorber for a wide frequency spectrum, to reduce the reverberation time. Acoustic insert is available in various colors of ecologically reared sheep’s wool, microperforated steel to match the luminaire.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low or Medium Power. Lifetime L85/50000h.
Installation:
Height-adjustable central cord suspension, parallel cord suspension with transparent power supply cable. Canopy finish matches luminaire body.
Certification & Warranty:
cETLus.
5 Years Warranty.
Product adjustments
Micro Perforated
Beige Wool
Green Wool
Graphite Wool
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Suspension | Acoustic absorber | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1RG1ASD-840E-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Microprismatic screen | Radiant Silver | 4000K | Dimmable (0-10V) | Central cord susp. (Set) | Absorber (White Perforated) | 3850lm | 35W | |
| 1RG1OWD-840E-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Snow White | 4000K | Dimmable (0-10V) | Central cord susp. (Set) | Absorber (White Perforated) | 4140lm | 35W | |
| 1RG1OSD-840E-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Radiant Silver | 4000K | Dimmable (0-10V) | Central cord susp. (Set) | Absorber (White Perforated) | 4140lm | 35W | |
| 1RG1OBD-840E-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Jet Black | 4000K | Dimmable (0-10V) | Central cord susp. (Set) | Absorber (White Perforated) | 4140lm | 35W | |
| 1RG1OWE-827M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Snow White | 2700K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W | |
| 1RG1OSE-827M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Radiant Silver | 2700K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W | |
| 1RG1OBE-827M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Jet Black | 2700K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W | |
| 1RG1OWE-830M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Snow White | 3000K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W | |
| 1RG1OSE-830M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Radiant Silver | 3000K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W | |
| 1RG1OBE-830M-D600-U-AW | Ringo Star-G1 Acoustic | D=23,6'' | Opal diffuser | Jet Black | 3000K | Switchable | Central cord susp. (Set) | Absorber (White Perforated) | 4899lm | 44W |
