Housing:
High-quality processed FRP (Fiberglass Reinforced Plastic). LED pendant luminaire with a rebated lens optic in a decorative ring. Direct-indirect or direct-only light distribution. Fully enclosed and damp rated.
Optical System:
Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Outer housing and Decorative reflector ring available in various finishes and combinations, e.g. white, silver, graphite, black, gold or copper coated. For further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Medium or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Installation:
Height-adjustable central cord suspension, parallel cord suspension with transparent power supply cable, or rod suspension. Colors ceiling rose and rod suspension match to luminaire body.
Certification & Warranty:
cETLus. 5 Years Warranty.
![](/site/assets/files/5457/beam-me-up-deep-suspended-g1-p1-0001-.0x556.png)
![](/site/assets/files/5457/beam-me-up-deep-suspended-g1-p1-0002.0x556.png)
![](/site/assets/files/5457/beam-me-up-deep-suspended-g1-p1-0003.0x556.png)
![](/site/assets/files/5457/beam-me-up-deep-suspended-g1-p1-0004.0x556.png)
![](/site/assets/files/5457/beam-me-up-deep-suspended-g1-p1-0005-.0x556.png)
Product adjustments
![](/site/assets/files/6014/beam-me-up-jr-champagne-silver.92x92.jpg)
Anodic Champagne | Anodic Champagne
![](/site/assets/files/6015/beam-me-up-jr-urban-graphite-urban-graphite.92x92.jpg)
Urban Graphite | Urban Graphite
![](/site/assets/files/6016/beam-me-up-jr-satin-copper-satin-copper.92x92.jpg)
Satin Copper | Satin Copper
![](/site/assets/files/6017/beam-me-up-jr-champagne-silver-jet-black.92x92.jpg)
Anodic Champagne | Jet Black
![](/site/assets/files/6018/beam-me-up-jr-jet-black-satin-gold.92x92.jpg)
Jet Black | Satin Gold
![](/site/assets/files/6019/beam-me-up-jr-jet-black-snow-white.92x92.jpg)
Jet Black | Snow White
Configuration and data download
Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Suspension | Reflector Color Inside | Luminous Flux | Power consumption |
---|---|---|---|---|---|---|---|---|---|---|---|
1MP1AWE-830H-D1200-KG | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 25385lm | 247W | |
1MP1AAE-830H-D1200-KA | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Satin Silver | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Silver | 25385lm | 247W | |
1MP1ABE-830H-D1200-KB | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Jet Black | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 25385lm | 247W | |
1MP1ABE-827M-D400-KB | Beam Me Up-P1 | D=15,7'' | Microprismatic screen | Jet Black | 2700K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 2038lm | 20W | |
1MP1ABE-827H-D1200-KB | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Jet Black | 2700K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 25385lm | 247W | |
1MP1ABE-827H-D1200-KG | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Jet Black | 2700K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 25385lm | 247W | |
1MP1ABD-840H-D1200-KB | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Jet Black | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Jet Black | 27150lm | 247W | |
1MP1AWE-830H-D1200-KW | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Snow White | 25385lm | 247W | |
1MP1AWE-830H-D1200-KB | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 25385lm | 247W | |
1MP1ABD-840H-D1200-KG | Beam Me Up-P1 | D=47,2'' | Microprismatic screen | Jet Black | 4000K | Dimmable (0-10V) | Parallel cord susp (Set) | Reflector: Satin Gold | 27150lm | 247W |
