Housing:
Extruded Aluminum. LED pendant luminaire with overall height of 2.25". Direct-Indirect or Direct only light distribution. Fully enclosed.
Optical System:
Recessed microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Outer housing and Decorative reflector ring available in various finishes and combinations, e.g. white, silver, graphite, black, gold or copper coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K, or Tunable White. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3-step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Medium or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Installation:
Height-adjustable central cord suspension with transparent power supply cable or rod suspension. Canopy and rod suspension finish matches luminaire body.
Certification & Warranty:
cETLus.
5 Years Warranty
Product adjustments
Snow White | Snow White
Radiant Silver | Radiant Silver
Urban Graphite | Urban Graphite
Jet Black | Jet Black
Anodic Champagne | Anodic Champagne
Satin Copper | Satin Copper
Snow White | Satin Copper
Snow White | Satin Gold
Snow White | Jet Black
Anodic Champagne | Jet Black
Jet Black | Satin Gold
Jet Black | Snow White
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Suspension | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1BP3AWD-830H-D300-PG | Basic-P3 | D=11,8'' | Microprismatic screen | Snow White | 3000K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Satin Gold | 2366lm | 23W | |
| 1BP3ASD-830H-D300-PS | Basic-P3 | D=11,8'' | Microprismatic screen | Radiant Silver | 3000K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Radiant Silver | 2366lm | 23W | |
| 1BP3AWD-827H-D600-PG | Basic-P3 | D=23,6'' | Microprismatic screen | Snow White | 2700K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Satin Gold | 7246lm | 63W | |
| 1BP3ASD-827H-D600-PS | Basic-P3 | D=23,6'' | Microprismatic screen | Radiant Silver | 2700K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Radiant Silver | 7246lm | 63W | |
| 1BP3ABD-827H-D600-PB | Basic-P3 | D=23,6'' | Microprismatic screen | Jet Black | 2700K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Jet Black | 7246lm | 63W | |
| 1BP3ABD-827H-D600-PG | Basic-P3 | D=23,6'' | Microprismatic screen | Jet Black | 2700K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Satin Gold | 7246lm | 63W | |
| 1BP3ASE-827H-D600-PS | Basic-P3 | D=23,6'' | Microprismatic screen | Radiant Silver | 2700K | Switchable | Rod susp. (Set) | Reflector: Radiant Silver | 7246lm | 63W | |
| 1BP3ABE-827H-D600-PB | Basic-P3 | D=23,6'' | Microprismatic screen | Jet Black | 2700K | Switchable | Rod susp. (Set) | Reflector: Jet Black | 7246lm | 63W | |
| 1BP3ABE-827H-D600-PG | Basic-P3 | D=23,6'' | Microprismatic screen | Jet Black | 2700K | Switchable | Rod susp. (Set) | Reflector: Satin Gold | 7246lm | 63W | |
| 1BP3AWD-827H-D600-PW | Basic-P3 | D=23,6'' | Microprismatic screen | Snow White | 2700K | Dimmable (0-10V) | Rod susp. (Set) | Reflector: Snow White | 7246lm | 63W |
