Housing:
Extruded Aluminum. LED pendant luminaire. Direct-indirect or direct-only light distribution. As standard available in 3 different sizes. Fully enclosed and damp rated.
Optical System:
Direct light with precision lenses with louver for wide uniform symmetrical light distribution with high glare limitation (UGR<19) especially for workplaces. Louver available in various color finishes. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting.
Surface Finish:
Standard color finishes white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection. RAL or PANTONE of your choice.
Control:
Integral electronic driver dimmable 0-10V. Minimum dimming level 1%. Field replaceable. On request: DALI, DMX, Lutron, Casambi.
LED:
Available color temperatures: 2200K, 2700K, 3000K, 3500K, 4000K, 6500K. All color temperatures available in CRI>80 or CRI>90. Optionally FULL SPECTRUM-LEDS for highest Fidelity Levels (Tm30). Tolerance within a 3 -step MacAdam ellipse. Up to 110lm/W efficacy. Choice of different lumen output levels: Low, Medium, or High Power. Custom lumen output upon request. Lifetime L85/50000h.
Installation:
Height-adjustable parallel cord suspension with transparent power supply cable. Colors canopy match to luminaire body.
Certification & Warranty:
cETLus.
5 Years Warranty.
Product adjustments
Snow White | Snow White
Snow White | Satin Silver
Snow White | Jet Black
Snow White | Satin Gold
Snow White | Anodic Champagne
Snow White | Satin Copper
Snow White
Satin Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (in) | Optical system | Surface finish | Color temperature | Control | Suspension | Reflector Color Inside | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1APXLWE-830E-Q640-KW | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Snow White | 6068lm | 50W | |
| 1APXLWE-830E-Q640-KB | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 6068lm | 50W | |
| 1APXLWE-830E-Q640-KG | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 6068lm | 50W | |
| 1APXLSE-830E-Q640-KA | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Radiant Silver | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Silver | 6068lm | 50W | |
| 1APXLBE-830E-Q640-KB | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Jet Black | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 6068lm | 50W | |
| 1APXLBE-830E-Q640-KG | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Jet Black | 3000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 6068lm | 50W | |
| 1APXLWE-840E-Q640-KW | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Snow White | 6490lm | 50W | |
| 1APXLWE-840E-Q640-KB | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Jet Black | 6490lm | 50W | |
| 1APXLWE-840E-Q640-KG | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Snow White | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Gold | 6490lm | 50W | |
| 1APXLSE-840E-Q640-KA | Caleo-PX Inverse | Q=25,2'' | Lens Louver | Radiant Silver | 4000K | Switchable | Parallel cord susp (Set) | Reflector: Satin Silver | 6490lm | 50W |
