LED surface-mounted luminaire for walls or ceilings. Omnidirectional light distribution. Luminaire body made of aluminium. Surface white, silver, graphite, black or champagne coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice. Ambient diffuser made of frosted acrylic glass for general lighting with maximum transmittance and homogeneous lighting. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K or 6500K. Binning ≤ MacAdam 3. Colour rendering CRI>80 or CRI>90. On request: Integration of emergency lighting components.
Product adjustments
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|
| CA7FSE-840M-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 4000K | Switchable | 1480lm | 12W | |
| CA7FSE-840H-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 4000K | Switchable | 2150lm | 15W | |
| CA7FSE-830M-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 3000K | Switchable | 1384lm | 12W | |
| CA7FSE-830H-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 3000K | Switchable | 2010lm | 15W | |
| CA7FSL-840M-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 4000K | Dimmable (DALI) | 1480lm | 12W | |
| CA7FSL-840H-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 4000K | Dimmable (DALI) | 2150lm | 15W | |
| CA7FSL-830M-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 3000K | Dimmable (DALI) | 1384lm | 12W | |
| CA7FSL-830H-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Radiant Silver | 3000K | Dimmable (DALI) | 2010lm | 15W | |
| CA7FBE-840M-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Jet Black | 4000K | Switchable | 1480lm | 12W | |
| CA7FBE-840H-Q300 | Cubic-A7 | L=300mm | Ambient diffuser | Jet Black | 4000K | Switchable | 2150lm | 15W |
