LED surface-mounted luminaire for walls and ceilings
Direct only light distribution. Luminaire body made of aluminum profile in 7 different diameters from 200mm to 1200mm – with overall height of 75mm. Surface white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice. Microprismatic screen with optimized glare reduction especially for workplaces. Opal diffuser made of acrylic glass. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K, 6500K or Tunable White (2700-6500K). Binning≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. On request: Integration of emergency lighting components, sensor technology.
Product adjustments
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|
| BA1ASE-830E-D1200 | Basic-A1 | D=1200mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 14119lm | 106W | |
| BA1ASE-830E-D200 | Basic-A1 | D=200mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 421lm | 5W | |
| BA1ASE-830E-D300 | Basic-A1 | D=300mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 823lm | 7W | |
| BA1ASE-830E-D400 | Basic-A1 | D=400mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 1627lm | 13W | |
| BA1ASE-830E-D500 | Basic-A1 | D=500mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 2319lm | 17W | |
| BA1ASE-830E-D600 | Basic-A1 | D=600mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 3609lm | 25W | |
| BA1ASE-830E-D900 | Basic-A1 | D=900mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 7405lm | 56W | |
| BA1ASE-830M-D1200 | Basic-A1 | D=1200mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 23282lm | 172W | |
| BA1ASE-830M-D200 | Basic-A1 | D=200mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 1038lm | 10W | |
| BA1ASE-830M-D300 | Basic-A1 | D=300mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 1618lm | 13W |
