Recessed mounted LED luminaire for ceilings with cut-out openings
Direct only light distribution. Luminaire body with surrounding frame made of aluminium. 7 different diameters from 220 to 1250mm. Surface white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice. Microprismatic screen with optimized glare reduction especially for workplaces. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K or 6500K. Binning≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Mounting brackets for assembly included. Vertical Installation not possible. On request: Integration of emergency lighting components.
Product adjustments
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|
| BM4ASE-830E-D320 | Basic-M4 | D=320mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 823lm | 7W | |
| BM4ASE-830E-D420 | Basic-M4 | D=420mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 1627lm | 13W | |
| BM4ASE-830E-D520 | Basic-M4 | D=520mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 2319lm | 17W | |
| BM4ASE-830E-D670 | Basic-M4 | D=670mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 3609lm | 25W | |
| BM4ASE-830M-D320 | Basic-M4 | D=320mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 1618lm | 13W | |
| BM4ASE-830M-D420 | Basic-M4 | D=420mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 3347lm | 25W | |
| BM4ASE-830M-D520 | Basic-M4 | D=520mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 4544lm | 33W | |
| BM4ASE-830M-D670 | Basic-M4 | D=670mm | Microprismatic screen | Radiant Silver | 3000K | Switchable | 6779lm | 50W | |
| BM4ASE-840E-D320 | Basic-M4 | D=320mm | Microprismatic screen | Radiant Silver | 4000K | Switchable | 880lm | 7W | |
| BM4ASE-840E-D420 | Basic-M4 | D=420mm | Microprismatic screen | Radiant Silver | 4000K | Switchable | 1740lm | 13W |
