LED pendant light system
Direct-indirect or direct-only light distribution. Lighting system with various combinations of the different X, Y and circular modules, each module available as stand-alone luminaire. A connector and a cord-holder have to be ordered separately for each joint. Furthermore entirely compatible with all Liquid Line G3/P3 modules. Luminaire body made of aluminium profile with 60mm profile width. Surface white, silver, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice. Optional internal acoustic absorber suitable for wide frequency spectrum, made from ecologically reared sheep’s wool or green moss. Satin opal diffuser for general lighting. Driver in each case integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K or 6500K. Binning≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Ceiling rose with transparent power supply cable to be ordered separately for each complete light structure. Colours ceiling rose match to luminaire body.
Product adjustments
Micro Perforated
Beige Wool
Green Wool
Graphite Wool
Green Moss
Snow White
Radiant Silver
Urban Graphite
Jet Black
Anodic Champagne
Satin Copper
Configuration and data download
| Downloads | Article code | Productname | Length L/Diameter D (mm) | Optical system | Surface finish | Colour temperature | Control | Suspension | Luminous Flux | Power consumption |
|---|---|---|---|---|---|---|---|---|---|---|
| RG3OSE-830M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Radiant Silver | 3000K | Switchable | lm on request | W on request | ||
| RG3OSL-830M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Radiant Silver | 3000K | Dimmable (DALI) | lm on request | W on request | ||
| RG3OSE-840M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Radiant Silver | 4000K | Switchable | lm on request | W on request | ||
| RG3OSL-840M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Radiant Silver | 4000K | Dimmable (DALI) | lm on request | W on request | ||
| RG3OBE-830M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Jet Black | 3000K | Switchable | lm on request | W on request | ||
| RG3OBE-840M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Jet Black | 4000K | Switchable | lm on request | W on request | ||
| RG3OBL-830M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Jet Black | 3000K | Dimmable (DALI) | lm on request | W on request | ||
| RG3OBL-840M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Jet Black | 4000K | Dimmable (DALI) | lm on request | W on request | ||
| RG3OWE-830M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Snow White | 3000K | Switchable | lm on request | W on request | ||
| RG3OWE-840M-#rings | Ringo Star Cluster-G3 | D=1000 mm/Ring | Opal diffuser | Snow White | 4000K | Switchable | lm on request | W on request |
